JIS SUM24L | DIN 1.0718 | ASTM 12L14 Cold Drawn Steel

Port: Hu nan

12L14 cold drawn steel, 12L14 alloy tool steel, 12L14 alloy steel, 12L14 alloy structural steel

Alloy Structural Steel, Alloy Tool Steel, Carbon Structural Steel, Carbon Tool Steel, Bearing Steel, Spring Steel ,Stainless Steel, Refractory Steel, Roll Steel, Pinion Steel. Additionally, the company also has the capacity to forge round steel, steel flat, square steel, module, shaft and roller


  • Quick Details

    1: 12L14 steel introduction

         12L14 is easy cutting structural steel, easy cutting steel is easy to be (turning, milling, drawing, planing, drilling, etc.) cutting processing steel, also known as automatic machine tool processing steel, referred to as automatic steel. It is produced to adapt to machining automation and flow line production.

    2: 12L14 steel equivalent

    Country China Japan Germany USA UK
    Standard GB JIS

    DIN (W-Nr.)

    EN 10277




    SUM24L 1.0718 12L14

    3: 12L14 steel chemical composition

    Grade C Si Mn P Pb
    1.0718 0.14 0.05 0.90-1.30 0.11 0.20-0.35
    12L14 0.15 0.26-0.35 0.85-1.15 0.04-0.09 0.15-0.35

    4: 12L14 steel mechanical properties

        The mechanical properties mainly include tensile strength, yield strength, elongation, area or reduction, hardness, impact value, non-metalic inclusion etc. Different heat treatment, the mechanical properties will be different, such as normalized, tempered, QT. If you want to know the properties, kindly contact the salesman.

    5: 12L14 steel overviews

    Size Round Dia 6-1200mm
    Plate/Flat/Block Thickness
    Heat treatment Normalized ; Annealed ; Quenched ; Tempered
    Surface condition Black; Peeled; Polished; Machined; Grinded; Turned; Milled
    Delivery condition Forged; Hot rolled; Cold drawn
    Test Tensile strength, Yield strength, elongation, area of reduction, impact value, hardness, grain size, ultrasonic test, US inspection, magnetic particle testing, etc.
    Payment terms T/T;L/C;/Money gram/ Paypal
    Trade terms FOB; CIF; C&F; etc..
    Delivery time 30-45 days
    Application  12L14 is mainly used for making instruments and meters, watch parts, automobiles, machine tools and other machines with small stress and strict requirements on size and finish. Standard parts with strict requirements for dimensional accuracy and smoothness and relatively low requirements for mechanical properties, such as gear, shaft, bolt, valve, bushing, pin, pipe joint, spring seat and machine tool lead screw, plastic molding die, surgical and dental appliances, etc.

    7: Delivery condition
        For hot forged  bar, usually the delivery condition is hot forged, annealed/QT, rough turned/Black surface.
        For hot rolled bar, usually the delivery condition is hot rolled, annealed/QT, Black surface.
        For hot forged block, usually the delivery condition is hot forged, annealed/QT, milled surface/Black surface
        For hot rolled plate, usually the delivery condition is hot rolled, annealed/QT, black surface.
        For cold drawn bar, usually the delivery condition is cold drawn, annealed/QT, peeled/black surface
