DIN 105WCr6/1.2419 Hot Work Tool Steel
Port: Hu nan
105WCr6 hot work tool steel, 105WCr6 tool steel, 105WCr6 alloy tool steel, 105WCr6 alloy steel, 1.2419 hot work tool steel
Alloy Structural Steel, Alloy Tool Steel, Carbon Structural Steel, Carbon Tool Steel, Bearing Steel, Spring Steel ,Stainless Steel, Refractory Steel, Roll Steel, Pinion Steel. Additionally, the company also has the capacity to forge round steel, steel flat, square steel, module, shaft and roller
1: 105WCr6 steel introduction
105WCr6 Steel is an oil hardening tool steel which is supplied in the annealed condition and characterized by its characteristics of offering good durability. 105WCr6 Steel is with excellent wear resistance and its ability to hold a good cutting edge.
2: 105WCr6 Steel equivalent
| Country | China | Japan | Germany | USA | UK |
| Standard | GB | JIS | DIN 17350 | ASTM | BS |
| Grade |
|
|
105WCr6 |
|
|
3: 105WCr6 steel chemical composition
| Grade | C | Mn | Cr | W | Si | |||
| 105WCr6 | 1.00-1.10 | 0.80-1.10 | 0.90-1.10 | 1.00-1.30 | 0.10-0.40 | |||
4: 105WCr6 steel mechanical properties
The mechanical properties mainly include tensile strength, yield strength, elongation, area or reduction, hardness, impact value, non-metalic inclusion etc. Different heat treatment, the mechanical properties will be different, such as normalized, tempered, QT. If you want to know the properties, kindly contact the salesman.
5: 105WCr6 steel overviews
| Size | Round | Dia 6-1200mm |
| Plate/Flat/Block |
Thickness 6mm-500mm |
|
|
Width 20mm-1000mm |
||
| Process | EAF+LF+VD+Forged+Heat treatment(optional) | |
| Heat treatment | Normalized ; Annealed ; Quenched ; Tempered | |
| Surface condition | Black; Peeled; Polished; Machined; Grinded; Turned; Milled | |
| Delivery condition | Forged; Hot rolled; Cold drawn | |
| Test | Tensile strength, Yield strength, elongation, area of reduction, impact value, hardness, grain size, ultrasonic test, US inspection, magnetic particle testing, etc. | |
| Payment terms | T/T;L/C;/Money gram/ Paypal | |
| Trade terms | FOB; CIF; C&F; etc.. | |
| Packing | Standard packages or as per customers request. | |
| Delivery time | 30-45 days | |
| Application | 105WCr6 is mainly used for quenching, which requires very little deformation. Long and complicated cutting tools (such as broaches, long taps, reamers, milling cutters) and measuring tools (such as die, block gauge, gauge, sample cylinder, sample sleeve) as well as cold die with small section and complicated shape. | |
6: Delivery condition
For hot forged or hot rolled bar, usually the delivery condition is hot forged or rolled, annealed, rough turned.
For hot forged plate, usually the delivery condition is hot forged, annealed, milled surface.
For hot rolled plate, usually the delivery condition is hot rolled, annealed, black surface.
