JIS SKH10 | DIN S12-1-4-5/1.3202 | ASTM T15 Hot Work Tool Steel
Port: Hu nan
1.3202 hot work tool steel, 1.3202tool steel, 1.3202 alloy tool steel, 1.3202 alloy steel, skh10 hot work tool steel
Alloy Structural Steel, Alloy Tool Steel, Carbon Structural Steel, Carbon Tool Steel, Bearing Steel, Spring Steel ,Stainless Steel, Refractory Steel, Roll Steel, Pinion Steel. Additionally, the company also has the capacity to forge round steel, steel flat, square steel, module, shaft and roller
1: 1.3202 steel introduction
1.3202 steel is one of high performance high-speed tungsten steel material.DIN 1.3202 tool steel is similar to 1.3302 high-speed steel but with added 5% cobalt. The high Vanadium content gives the steel the best cutting performance and durability. The Cobalt content offers high tempering durability and hot hardness.It is the preferred material of aviation alloy, high temperature alloy spiral flat broach, and tap and die milling cutter for hard cutting material and quenched and tempered material
2: 1.3202 Steel equivalent
| Country | China | Japan | Germany | USA | UK |
| Standard | GB | JIS | DIN 17350 | ASTM | BS |
| Grade |
|
SKH10 | S12-1-4-5 | T15 |
|
3: 1.3202 steel chemical composition
| Grade | C | Mo | Cr | V | Co | W | |||
| S12-1-4-5 | 1.30-1.45 | 0.70-1.00 | 3.80-4.50 | 3.50-4.00 | 4.50-5.00 | 11.5-12.5 | |||
| T15 | 1.55 | 0.38 | 4.00 | 5.00 | 5.00 | 13.0 | |||
4: 1.3202 steel mechanical properties
The mechanical properties mainly include tensile strength, yield strength, elongation, area or reduction, hardness, impact value, non-metalic inclusion etc. Different heat treatment, the mechanical properties will be different, such as normalized, tempered, QT. If you want to know the properties, kindly contact the salesman.
5: 1.3202 steel overviews
| Size | Round | Dia 6-1200mm |
| Plate/Flat/Block |
Thickness 6mm-500mm |
|
|
Width 20mm-1000mm |
||
| Process | EAF+LF+VD+Forged+Heat treatment(optional) | |
| Heat treatment | Normalized ; Annealed ; Quenched ; Tempered | |
| Surface condition | Black; Peeled; Polished; Machined; Grinded; Turned; Milled | |
| Delivery condition | Forged; Hot rolled; Cold drawn | |
| Test | Tensile strength, Yield strength, elongation, area of reduction, impact value, hardness, grain size, ultrasonic test, US inspection, magnetic particle testing, etc. | |
| Payment terms | T/T;L/C;/Money gram/ Paypal | |
| Trade terms | FOB; CIF; C&F; etc.. | |
| Packing | Standard packages or as per customers request. | |
| Delivery time | 30-45 days | |
| Application | 1.3202 Steel is used to make complex blanking, high speed drill pipe, vibration and shock loading dies: deep dies, punch dies, metal cutting saw blades, cold heading and extrusion tools. It is also used for high speed steel and for heavy duty work. Turning tool and milling cutter for rough machining and trimming. | |
6: Delivery condition
For hot forged or hot rolled bar, usually the delivery condition is hot forged or rolled, annealed, rough turned.
For hot forged plate, usually the delivery condition is hot forged, annealed, milled surface.
For hot rolled plate, usually the delivery condition is hot rolled, annealed, black surface.
