DIN C85W/1.1830 Hot Work Tool Steel
Port: Hu nan
C85W hot work tool steel, C85W tool steel, C85W alloy tool steel, C85W alloy steel, 1.1830 hot work tool steel
Alloy Structural Steel, Alloy Tool Steel, Carbon Structural Steel, Carbon Tool Steel, Bearing Steel, Spring Steel ,Stainless Steel, Refractory Steel, Roll Steel, Pinion Steel. Additionally, the company also has the capacity to forge round steel, steel flat, square steel, module, shaft and roller
1: C85W steel introduction
C85W steel with carbon content slightly higher than eutectoid point. It is the lowest alloy grade of all tool steels used for machining. Although its hardness is similar to that of higher carbon steels, it has lower wear resistance and poorer cutting edges.
2: C85W Steel equivalent
| Country | China | Japan | Germany | USA | UK |
| Standard | GB | JIS | DIN 17350 | ASTM | BS |
| Grade |
|
|
C85W |
|
|
3: C85W steel chemical composition
| Grade | C | Mn | P | S | Si | |||
| C85W | 0.80-0.90 | 0.50-0.70 | 0.025 | 0.02 | 0.25-0.40 | |||
4: C85W steel mechanical properties
The mechanical properties mainly include tensile strength, yield strength, elongation, area or reduction, hardness, impact value, non-metalic inclusion etc. Different heat treatment, the mechanical properties will be different, such as normalized, tempered, QT. If you want to know the properties, kindly contact the salesman.
5: C85W steel overviews
| Size | Round | Dia 6-1200mm |
| Plate/Flat/Block |
Thickness 6mm-500mm |
|
|
Width 20mm-1000mm |
||
| Process | EAF+LF+VD+Forged+Heat treatment(optional) | |
| Heat treatment | Normalized ; Annealed ; Quenched ; Tempered | |
| Surface condition | Black; Peeled; Polished; Machined; Grinded; Turned; Milled | |
| Delivery condition | Forged; Hot rolled; Cold drawn | |
| Test | Tensile strength, Yield strength, elongation, area of reduction, impact value, hardness, grain size, ultrasonic test, US inspection, magnetic particle testing, etc. | |
| Payment terms | T/T;L/C;/Money gram/ Paypal | |
| Trade terms | FOB; CIF; C&F; etc.. | |
| Packing | Standard packages or as per customers request. | |
| Delivery time | 30-45 days | |
| Application | C85W steel used in chisels, punches, knives, woodworking tools, taps. | |
6: Delivery condition
For hot forged or hot rolled bar, usually the delivery condition is hot forged or rolled, annealed, rough turned.
For hot forged plate, usually the delivery condition is hot forged, annealed, milled surface.
For hot rolled plate, usually the delivery condition is hot rolled, annealed, black surface.
