DIN S6-5-3/1.3344 | ASTM M3/2 Hot Work Tool Steel

Port: Hu nan

S6-5-3 hot work tool steel, S6-5-3 tool steel, S6-5-3 alloy tool steel, S6-5-3 alloy steel, 1.3344 hot work tool steel, M3/2 hot work tool steel

Alloy Structural Steel, Alloy Tool Steel, Carbon Structural Steel, Carbon Tool Steel, Bearing Steel, Spring Steel ,Stainless Steel, Refractory Steel, Roll Steel, Pinion Steel. Additionally, the company also has the capacity to forge round steel, steel flat, square steel, module, shaft and roller

E-mail:export@qilucs.com

  • Quick Details

    1: M3/2 steel introduction

           M3/2 is a tungsten-molybdenum high speed tool steel designed to provide excellent wear resistance for demanding cutting operations, with high C and V content, resulting in optimum durability and cutting performance.


    2: M3/2 Steel equivalent

    Country China Japan Germany USA UK
    Standard GB JIS DIN 17350 ASTM BS
    Grade

    S6-5-3 M3/2


    3: M3/2 steel chemical composition

    Grade C Mo Cr V W
    S6-5-3 1.17-1.27 4.70-5.20 3.80-4.50 2.70-3.20
    6.00-6.70


    4: M3/2 steel mechanical properties

        The mechanical properties mainly include tensile strength, yield strength, elongation, area or reduction, hardness, impact value, non-metalic inclusion etc. Different heat treatment, the mechanical properties will be different, such as normalized, tempered, QT. If you want to know the properties, kindly contact the salesman.


    5: M3/2 steel overviews

    Size Round Dia 6-1200mm
    Plate/Flat/Block Thickness
    6mm-500mm
    Width
    20mm-1000mm
    Process EAF+LF+VD+Forged+Heat treatment(optional)
    Heat treatment Normalized ; Annealed ; Quenched ; Tempered
    Surface condition Black; Peeled; Polished; Machined; Grinded; Turned; Milled
    Delivery condition Forged; Hot rolled; Cold drawn
    Test Tensile strength, Yield strength, elongation, area of reduction, impact value, hardness, grain size, ultrasonic test, US inspection, magnetic particle testing, etc.
    Payment terms T/T;L/C;/Money gram/ Paypal
    Trade terms FOB; CIF; C&F; etc..
    Packing  Standard packages or as per customers request.
    Delivery time 30-45 days
    Application  M3/2 is used for high performance milling cutters, reamers, broaches and cold working steels for machining hard materials, such as punching dies for nuts.


    6: Delivery condition

        For hot forged or hot rolled bar, usually the delivery condition is hot forged or rolled, annealed, rough turned.
        For hot forged plate, usually the delivery condition is hot forged, annealed, milled surface.

        For hot rolled plate, usually the delivery condition is hot rolled, annealed, black surface.
