DIN 45CrMoV7/1.2328 Hot Work Tool Steel
Port: Hu nan
45CrMoV7 hot work tool steel, 45CrMoV7 tool steel, 45CrMoV7 alloy tool steel, 45CrMoV7 alloy steel, 1.2328 hot work tool steel
Alloy Structural Steel, Alloy Tool Steel, Carbon Structural Steel, Carbon Tool Steel, Bearing Steel, Spring Steel ,Stainless Steel, Refractory Steel, Roll Steel, Pinion Steel. Additionally, the company also has the capacity to forge round steel, steel flat, square steel, module, shaft and roller
1: 45CrMoV7 steel introduction
45CrMoV7 is a high hardness and toughness air hardening steel. It has good wear resistance. The steel is meant to be air-hardened, which reduces the risk of deformations and cracks during the heat treatment.
2: 45CrMoV7 Steel equivalent
| Country | China | Japan | Germany | USA | UK |
| Standard | GB | JIS | DIN 17350 | ASTM | BS |
| Grade |
|
|
45CrMoV7 |
|
|
3: 45CrMoV7 steel chemical composition
| Grade | C | Mn | Cr | Si | Mo | V | |||
|
45CrMoV7 |
0.42-0.47 | 0.85-1.00 | 1.70-1.90 |
0.20-0.30 |
0.25-0.30 |
0.05 | |||
4: 45CrMoV7 steel mechanical properties
The mechanical properties mainly include tensile strength, yield strength, elongation, area or reduction, hardness, impact value, non-metalic inclusion etc. Different heat treatment, the mechanical properties will be different, such as normalized, tempered, QT. If you want to know the properties, kindly contact the salesman.
5: 45CrMoV7 steel overviews
| Size | Round | Dia 6-1200mm |
| Plate/Flat/Block |
Thickness 6mm-500mm |
|
|
Width 20mm-1000mm |
||
| Process | EAF+LF+VD+Forged+Heat treatment(optional) | |
| Heat treatment | Normalized ; Annealed ; Quenched ; Tempered | |
| Surface condition | Black; Peeled; Polished; Machined; Grinded; Turned; Milled | |
| Delivery condition | Forged; Hot rolled; Cold drawn | |
| Test | Tensile strength, Yield strength, elongation, area of reduction, impact value, hardness, grain size, ultrasonic test, US inspection, magnetic particle testing, etc. | |
| Payment terms | T/T;L/C;/Money gram/ Paypal | |
| Trade terms | FOB; CIF; C&F; etc.. | |
| Packing | Standard packages or as per customers request. | |
| Delivery time | 30-45 days | |
| Application | 45CrMoV7 is used as tool steel for cold working die tools, stamping parts and punches. | |
6: Delivery condition
For hot forged or hot rolled bar, usually the delivery condition is hot forged or rolled, annealed, rough turned.
For hot forged plate, usually the delivery condition is hot forged, annealed, milled surface.
For hot rolled plate, usually the delivery condition is hot rolled, annealed, black surface.
