GB OCr17Ni12Mo2 | JIS SUS316 | DIN X5CrNiMo17-12-2/1.4401 | ASTM 316 Stainless Steel

Port: Hu nan

engineering steel, cold work tool steel, hot work tool steel, plastic mold steel, spring steel, high speed steel, stainless steel

Alloy Structural Steel, Alloy Tool Steel, Carbon Structural Steel, Carbon Tool Steel, Bearing Steel, Spring Steel ,Stainless Steel, Refractory Steel, Roll Steel, Pinion Steel. Additionally, the company also has the capacity to forge round steel, steel flat, square steel, module, shaft and roller

E-mail：export@qilucs.com

Product Detail
  • Quick Details

    1: 316L steel introduction
        SAE 316L grade stainless steel, sometimes referred to as A4 stainless steel or marine grade stainless steel, is the second most common austenitic stainless steel after 304/A2 stainless steel. Its primary alloying constituents after iron, are chromium (between 16-18%), nickel (10-12%) and molybdenum (2-3%), with small (<1%) quantities of silicon, phosphorus & sulfur also present. The addition of molybdenum provides greater corrosion resistance than 304, with respect to localized corrosive attack by chlorides and to general corrosion by reducing acids, such as sulfuric acid.[1] 316L grade is the low carbon version of 316 stainless steel. When cold worked, 316 can produce high yield and tensile strengths similar to Duplex stainless grades.
        For elevated temperature applications the high carbon variant, 316H stainless steel and the stabilised grade 316Ti stainless steel should be employed.

    2: 316L Steel equivalent
    Country Japan Germany USA China
    Standard JIS DIN ASTM GB/T
    Grade SUS316L 1.4436 316L 07Cr17Ni14Mo2

    3: 316L steel chemical composition
    Grade C≤ Si≤ Mn≤ P≤ S≤ Cr Mo Ni N≤
    316L 0.03 0.75 2.0 0.045 0.04 16-18 2-3 10-14 0.1
    1.4436 0.05 1.0 2.0 0.045 0.03 16.5-18.5 2.5-3.0 10.5-13 0.1

    4: 316L steel mechanical properties

        The mechanical properties mainly include tensile strength, yield strength, elongation, area or reduction, hardness, impact value, non-metalic inclusion etc. Different heat treatment, the mechanical properties will be different, such as annealed, Solid Solution. If you want to know the properties, kindly contact the salesman.


    5: 316L steel overviews
    Size Round Dia 0.1-500mm
    Plate/Flat/Block Thickness
    0.3mm-200mm
    Width
    1mm-2500mm
    Heat treatment Annealed ; Solid Solution
    Surface condition Black; Peeled; Polished; Machined;Sand blast etc
    Delivery condition Forged; Hot rolled; Cold drawn
    Test Tensile strength, Yield strength, elongation, area of reduction, impact value, hardness, grain size, ultrasonic test, US inspection, magnetic particle testing, etc.
    Payment terms T/T;L/C;/Money gram/ Paypal
    Trade terms FOB; CIF; C&F; etc..
    Delivery time 30-45 days
    Application 316L stainless steels are used for food processing equipment;Brewery equipment;Chemical and petrochemical equipment;Laboratory benches & equipment;Coastal architectural panelling;Coastal balustrading;Boat fittings;Chemical transportation containers;Heat exchangers;Mining screens;Nuts and bolts;Springs;Medical implants

    6: Delivery condition
        For hot forged  bar, usually the delivery condition is hot forged, annealed/solid solution, rough turned/Black surface.
        For hot rolled bar, usually the delivery condition is hot rolled, annealed/solid solution, Black surface.
        For hot rolled plate, usually the delivery condition is hot rolled, annealed/solid solution, black surface.
        For cold drawn bar, usually the delivery condition is cold drawn, annealed/QT, peeled/black surface
