GB Q235C | DIN S235J0 / ST37-3 U Engineering Steel
Port: Hu nan
Q235C engineering steel, Q235C alloy tool steel, S235J0 carbon steel
Alloy Structural Steel, Alloy Tool Steel, Carbon Structural Steel, Carbon Tool Steel, Bearing Steel, Spring Steel ,Stainless Steel, Refractory Steel, Roll Steel, Pinion Steel. Additionally, the company also has the capacity to forge round steel, steel flat, square steel, module, shaft and roller
1: DIN S235J0 steel introduction
S235J0 is a carbon structural steel, which contains less than 0.8% carbon. It contains less sulfur, phosphorus and non-metallic inclusions than carbon structural steel, and has better mechanical properties.
2: DIN S235J0 Steel equivalent
Country
China
Japan
Germany
USA
British
Standard
GB/T 700
JIS G3101
DIN (W-Nr.)
EN 10025-2 / DIN17100
AISI/ASTM
ASTM A36
BS
Grade
Q235C
S235J0 / ST37-3 U
3: DIN S235J0 steel chemical composition
Grade
C
Si
Mn
P
S
Cr
Cu
Ni
S235J0 / ST37-3 U
0.17
0.50
1.40
0.03
0.03
/
0.55
/
Q235C
0.20
0.55
1.40
0.045
0.035
0.30
0.30
0.30
4: DIN S235J0 steel mechanical properties
The mechanical properties mainly include tensile strength, yield strength, elongation, area or reduction, hardness, impact value, non-metalic inclusion etc. Different heat treatment, the mechanical properties will be different, such as normalized, tempered, QT. If you want to know the properties, kindly contact the salesman.
5: DIN S235J0 steel overviews
| Size | Round | Dia 6-1200mm |
| Plate/Flat/Block |
Thickness 6mm-500mm |
|
|
Width 20mm-1000mm |
||
| Heat treatment | Normalized ; Annealed ; Quenched ; Tempered | |
| Surface condition | Black; Peeled; Polished; Machined; Grinded; Turned; Milled | |
| Delivery condition | Forged; Hot rolled; Cold drawn | |
| Test | Tensile strength, Yield strength, elongation, area of reduction, impact value, hardness, grain size, ultrasonic test, US inspection, magnetic particle testing, etc. | |
| Payment terms | T/T;L/C;/Money gram/ Paypal | |
| Trade terms | FOB; CIF; C&F; etc.. | |
| Delivery time | 30-45 days | |
| Application | S235J0 has a wide range of applications machinery, mining machinery, machinery manufacturing and other fields | |
6. DIN S235J0 Steel Heat Treatment
Hot rolled non-alloy quality steel S235J0 is suitable for welded construction. The steel is not suitable for heat treatment and stress-relief annealing is allowed.
7: Delivery condition
For hot forged bar, usually the delivery condition is hot forged, annealed/QT, rough turned/Black surface.For hot rolled bar, usually the delivery condition is hot rolled, annealed/QT, Black surface.
