GB 20 | JIS S20C | DIN C20/1.1151 | AISI 1020 | EN BS EN3B /070M20 Engineering Steel

Port: Hu nan

Supply Ability: 10,000 Ton/Tons per Year

Min.Order Quantity: 1 Piece/Pieces

E-mail:export@qilucs.com

  • Quick Details

    1: AISI 1020 steel introduction
        AISI 1020 Steel is a low hardenability and low tensile carbon steel. it offers excellent mechanical and chemical properties like high strength ductility, weldability, and high corrosion resistance. it is normally used in turned and polished or cold drawn condition.
        Due to its low carbon content, it is resistant to induction hardening or flame hardening. it will not respond to nitriding due to lack of alloying elements. However, carburization is possible in order to obtain case hardness more than Rc65 for smaller sections that reduce with an increase in section size.
        AISI 1020 steel can be largely utilized in all industrial sectors in order to enhance weldability or machinability properties. it is used in a variety of applications due to its cold drew or turned and polished finish property.

    2: AISI 1020 Steel equivalent
    Country China Japan Germany USA UK
    Standard GB/T 699 DIN (W-Nr.)
    JIS G4051
    EN 10083-2 AISI/ASTM
    ASTM A20
    EN / BS
    Grade 20 S20C C20/1.1151 1020
    EN3B /070M20

    3: AISI 1020 steel chemical composition
    Grade C Mn P S
    1020 0.18
    0.23
    0.30
    0.60
    0.04
    0.05

    4: AISI 1020 steel mechanical properties

      The mechanical properties mainly include tensile strength, yield strength, elongation, area or reduction, hardness, impact value, non-metalic inclusion etc. Different heat treatment, the mechanical properties will be different, such as normalized, tempered, QT. If you want to know the properties, kindly contact the salesman.


    5: AISI 1020 steel overviews

    Size Round Dia 6-1200mm
    Plate/Flat/Block Thickness
    6mm-500mm
    Width
    20mm-1000mm
    Process EAF+LF+VD+Forged+Heat treatment(optional)
    Heat treatment Normalized ; Annealed ; Quenched ; Tempered
    Surface condition Black; Peeled; Polished; Machined; Grinded; Turned; Milled
    Delivery condition Forged; Hot rolled; Cold drawn
    Test Tensile strength, Yield strength, elongation, area of reduction, impact value, hardness, grain size, ultrasonic test, US inspection, magnetic particle testing, etc.
    Payment terms T/T;L/C;/Money gram/ Paypal
    Trade terms FOB; CIF; C&F; etc..
    Delivery time 30-45 days
    Application  AISI 1020 is suitable for applications such as gears, shafts, crankshafts, camshafts, guide pins, gear rings, columns, turnstiles, covers, Pins,Shafts,Chains,Lightly stressed gears,Hard wearing surfaces,Case hardened components where core strength is not essential.

    6: Heat Treatment
    AISI 1020 carbon steel can be hardened by heating between 815- 871°C (1500 - 1600°F), which should be followed by water quenching. Then it should be tempered.
    Forging
    AISI 1020 carbon steel should be forged at 1260°C (2300°F) down to 982°C (1800°F).
    Hot Working
    AISI 1020 carbon steel can be hot worked in the range of 482 to 649°C (900 to 1200°F).
    Cold Working
    Cold working AISI 1020 carbon steel is possible using all the conventional methods. In case of prolonged cold working, it is recommended that stress relief annealing be carried out.
    Annealing
    Complete annealing of this alloy can be achieved between 871-982°C (1600 to 1800°F) followed by slow furnace cooling. This will provide the alloy with a tensile strength of about 65 ksi. A stress relief annealing can be performed if required at 538°C (1000°F).
    Tempering
    Tempering should be followed by heat treatment and quenching at 315 to 538°C (600 to 1000°F) based on the strength level required. For example 538°C (1000°F) temper provides the alloy with a tensile strength of 90 ksi.
    Hardening
    AISI 1020 carbon steel can be hardened by cold working and by heat treatment, quenching and tempering.


    7: Delivery condition
    For hot forged or hot rolled bar, usually the delivery condition is hot forged or rolled, annealed, rough turned.
    For hot forged plate, usually the delivery condition is hot forged, annealed, milled surface.

    For hot rolled plate, usually the delivery condition is hot rolled, annealed, black surface.
