JIS SCM415 | DIN 16MnCr5 / 1.7131 | ASTM 5115 Engineering Steel

Port: Hu nan

engineering steel, cold work tool steel, hot work tool steel, plastic mold steel, spring steel, high speed steel, stainless steel

Alloy Structural Steel, Alloy Tool Steel, Carbon Structural Steel, Carbon Tool Steel, Bearing Steel, Spring Steel ,Stainless Steel, Refractory Steel, Roll Steel, Pinion Steel. Additionally, the company also has the capacity to forge round steel, steel flat, square steel, module, shaft and roller

E-mail：export@qilucs.com

Product Detail
  • Quick Details

    1: 5115 steel introduction
        ASTM 5115 steel round bar is a kind of structural alloy steel under the  ASTM A29/A29M-04 standard, and it  is a common low carbon alloy carburizing steel. ASTM5115 has high cold deformation and plastic,good weldability and good  machinability under the condition annealing.

    2: 5115 Steel equivalent
    Country Germany USA
    Standard EN 10083-3 ASTM A29
    Grade 16MnCr5/1.7131 5115

    3: 5115 steel chemical composition
    Grade C Si Mn P S Cr Mo Ni
    5115 0.13-0.18 0.15-0.35 0.7-0.9 0.035 0.035 0.7-0.9 / 0.03
    1.7131 0.14-0.19 0.4 1-1.3 0.025 0.035 1.8-1.1 / 0.03

    4: 5115 steel mechanical properties

        The mechanical properties mainly include tensile strength, yield strength, elongation, area or reduction, hardness, impact value, non-metalic inclusion etc. Different heat treatment, the mechanical properties will be different, such as normalized, tempered, QT. If you want to know the properties, kindly contact the salesman.


    5: 5115 steel overviews
    Size Round Dia 6-1200mm
    Plate/Flat/Block Thickness
    6mm-500mm
    Width
    20mm-1000mm
    Heat treatment Normalized ; Annealed ; Quenched ; Tempered
    Surface condition Black; Peeled; Polished; Machined; Grinded; Turned; Milled
    Delivery condition Forged; Hot rolled; Cold drawn
    Test Tensile strength, Yield strength, elongation, area of reduction, impact value, hardness, grain size, ultrasonic test, US inspection, magnetic particle testing, etc.
    Payment terms T/T;L/C;/Money gram/ Paypal
    Trade terms FOB; CIF; C&F; etc..
    Delivery time 30-45 days
    Application 5115 are used for civil and industrial construction, means of transport, electionics and medical use; in particular we manufacture filters, injector, connectors, inserts, machined metal parts, adapters, shafts, gears, tie rods and screws.

    6: Delivery condition
        For hot forged bar, usually the delivery condition is hot forged, annealed/QT rough turned/Black surface.
        For hot rolled bar, usually the delivery condition is hot rolled, annealed/QT, Black surface.
        For hot forged plate, usually the delivery condition is hot forged, annealed/QT, milled surface
        For hot rolled plate, usually the delivery condition is hot rolled, annealed/QT, black surface.
