GB Q235D | DIN S235J2 Engineering Steel

Port: Hu nan

Q235D engineering steel, Q235D alloy tool steel, S235J2 carbon steel, S235J2 alloy tool steel

Alloy Structural Steel, Alloy Tool Steel, Carbon Structural Steel, Carbon Tool Steel, Bearing Steel, Spring Steel ,Stainless Steel, Refractory Steel, Roll Steel, Pinion Steel. Additionally, the company also has the capacity to forge round steel, steel flat, square steel, module, shaft and roller

E-mail:export@qilucs.com

  • Quick Details

    1: DIN S235J2 steel introduction

        The S235J2 steel (1.0117 material) is an non-alloy carbon steel steel grade in accordance with EN 10025-2. “S” stands for structural steel; “235” means the minimum yield strength (MPa) for the steel thickness ≤ 16 mm; “J2” refers to the impact energy 27J at -20 °C.


    2: DIN S235J2 Steel equivalent

    Country China Japan Germany USA British
    Standard GB/T 700 JIS G3101 DIN (W-Nr.)
    EN 10025-2 / DIN17100
    AISI/ASTM
    ASTM A36
    BS
    Grade Q235D
    S235J2


    3: DIN S235J2 steel chemical composition

    Grade C Si Mn P S Cr Cu Ni
    S235J2 0.17 0.35 1.40 0.025 0.025 / 0.55 /
    Q235D 0.20 0.55 1.40 0.045 0.035 0.30 0.30 0.30

    4: DIN S235J2 steel mechanical properties

        The mechanical properties mainly include tensile strength, yield strength, elongation, area or reduction, hardness, impact value, non-metalic inclusion etc. Different heat treatment, the mechanical properties will be different, such as normalized, tempered, QT. If you want to know the properties, kindly contact the salesman.


    5: DIN S235J2 steel overviews

    Size Round Dia 6-1200mm
    Plate/Flat/Block Thickness
    6mm-500mm
    Width
    20mm-1000mm
    Heat treatment Normalized ; Annealed ; Quenched ; Tempered
    Surface condition Black; Peeled; Polished; Machined; Grinded; Turned; Milled
    Delivery condition Forged; Hot rolled; Cold drawn
    Test Tensile strength, Yield strength, elongation, area of reduction, impact value, hardness, grain size, ultrasonic test, US inspection, magnetic particle testing, etc.
    Payment terms T/T;L/C;/Money gram/ Paypal
    Trade terms FOB; CIF; C&F; etc..
    Delivery time 30-45 days
    Application  S235J2 is widely used in railways, bridges, and various structural members. It is mainly used in building, bridge, ship, vehicle structural parts, manufacturing various tools, cutting tools, molds and measuring tools.

    6: Delivery condition

        For hot forged  bar, usually the delivery condition is hot forged, annealed/solid solution, rough turned/Black surface.
        For hot rolled bar, usually the delivery condition is hot rolled, annealed/solid solution, Black surface.
        For hot rolled plate, usually the delivery condition is hot rolled, annealed/solid solution, black surface.

        For cold drawn bar, usually the delivery condition is cold drawn, annealed/QT, peeled/black surface
